BUNKER MINI
BUNKER MINI is a compact, tracked robot for off-road and challenging areas, repelling sand, dust, and water, with a 25KG payload and 690*570*335MM dimensions.
Image Gallery
Specifications
Dimensions
660mm x 584mm x 281mm
Weight
54.8kg
Payload
35kg
Operating Temperature
-20°C to 60°C
IP Rating
IP67
Max Speed
1.5 m/s
Track Width
100mm
Battery
24V30Ah
Communication
CAN
Key Features
Seamless Maneuverability
Seamless Maneuverability - Demonstrates seamless spot rotations by independently driving its tracks in opposing directions for precise maneuvers in confined spaces
Advanced Suspension System
Advanced Suspension System - Offers exceptional flexibility with low center of gravity, 1800W dual-motor drive for obstacle crossing and climbing
Expansion and Secondary Development
Expansion and Secondary Development - Offers aluminum T-slot rails for mounting, supports CAN bus, open-source SDK
Product Description
BUNKER MINI is a compact, tracked robot for off-road and challenging areas, repelling sand, dust, and water, with a 25KG payload and 690*570*335MM dimensions.
Frequently Asked Questions
Standard delivery is 4-6 weeks for most models. Express shipping options are available for urgent requirements.
The product supports ROS 1 (Melodic, Noetic) and ROS 2 (Foxy, Humble), with comprehensive SDK documentation and examples.
Yes, we offer customization services including sensor integration, payload modifications, and software customization to meet specific requirements.
All products come with a 1-year warranty and lifetime technical support. Extended warranty options are available.
